Multimeter UNI-T UT222 clamp
Multimeter UNI-T UT222 clamp
Estimated shipping date:
3. 6. 2024 at our place
250,149 €
206,735 € excl. VAT
/ 120,000 €
Catalogue Code: 07720179
EAN: 6935750502228
Warranty: 24 Months
Manufacturer: UNI-T
-
Czech companywith 32 years' experience
-
Free shippingif you spend more than 120 €
-
Delivery within a weekif you place your order before 11:00 AM
Multimeter UNI-T UT222 clamp
Estimated shipping date:
3. 6. 2024 at our place
Description
UNI-T UT222 - 2500A clamp meter
SPECIFICATION
Alternate Current
600A/2500A ±(1.5%+5)
Direct Current
600A/2500A ±(1.5%+5)
Alternate Voltage
6V/60V/600V/1000V ±(1%+3)
Direct Voltage
6V/60V/600V/750V ±(0.5%+2)
Resistance
600Ω/6kΩ/60kΩ/600kΩ/6MΩ/600MΩ ±(1%+2)
Frequency
60Hz/600Hz/6kHz/60kHz/600kHz/6MHz/600MHz ±(0.1%+3)
Temperature
-40°C ~ 1000°C* ±(1%+10)
FUNCTIONS
Display Count 6000
Auto Range
Jaw Opening 63mm
TRMS
Duty Cycle
Low-pass filter
Inrush Current
Relative Function
Diode Test
Continuity buzzer
Data Hold
Max mode
Analogue Bargraf 61
Datalogging 1000
I-OUT function
Display Backlight
Iconic Display
Auto Power Off
Low Battery Indication
Input Impedance 10MΩ+
GENERAL CHARACTERISTICS
Power: 9V alkaline battery
Size: 298x100x48mm
LCD Size: 43x30mm
Weight: 725g
SPECIFICATION
Alternate Current
600A/2500A ±(1.5%+5)
Direct Current
600A/2500A ±(1.5%+5)
Alternate Voltage
6V/60V/600V/1000V ±(1%+3)
Direct Voltage
6V/60V/600V/750V ±(0.5%+2)
Resistance
600Ω/6kΩ/60kΩ/600kΩ/6MΩ/600MΩ ±(1%+2)
Frequency
60Hz/600Hz/6kHz/60kHz/600kHz/6MHz/600MHz ±(0.1%+3)
Temperature
-40°C ~ 1000°C* ±(1%+10)
FUNCTIONS
Display Count 6000
Auto Range
Jaw Opening 63mm
TRMS
Duty Cycle
Low-pass filter
Inrush Current
Relative Function
Diode Test
Continuity buzzer
Data Hold
Max mode
Analogue Bargraf 61
Datalogging 1000
I-OUT function
Display Backlight
Iconic Display
Auto Power Off
Low Battery Indication
Input Impedance 10MΩ+
GENERAL CHARACTERISTICS
Power: 9V alkaline battery
Size: 298x100x48mm
LCD Size: 43x30mm
Weight: 725g
Categorized into following categories:Clamp multimeters
Parameters and specifications
Max. DC voltage:
Max. AC voltage:
Max. DC current:
Max. AC current:
Punching range:
Measured quantities:
Special Features:
Multimeter resolution:
